Main saw power: 16.5kw
Auxiliary saw motor power: 2.2kw
Maximum sawing length: 1250mm
Maximum sawing thickness: 90mm
Maximum sawing width: 1250mm
Minimum board size for horizontal cutting: 5mm
Minimum vertical cutting board size: 40mm
Positioning method: automatic
Servo positioning accuracy: 0.02mm
Sawing accuracy: ± 0.1mm
Main saw blade outer diameter: 360mm
Main saw blade inner diameter: 75mm
Main saw speed/frequency converter speed regulation: 4800r/min
Traction motor power (rack drive): 1.0KW
Mechanical arm servo motor: 1.0kw
Sawing speed: 0-100 meters per minute
Return speed: 120 meters per minute
High pressure fan: 2.2KW
Air pressure: 0.6-0.8MPA
Specification of air flotation table: 1750x540mm 1 piece
Machine tool dimensions: 3000 * 4400 * 1850mm
Total power: 23KW
Display screen: 7 inches
Retaining the flexibility of traditional electronic cutting saws in randomly manually arranging cutting data, and expanding intelligent data import and wireless remote start stop operation
Features such as remote monitoring have been added, along with practical functions such as order design, order splitting optimization, surplus material management, layout optimization, and barcode printing. same
Open docking for all software ports, such as Circle Square, Huaguang CV、 1010, Weilun, Haixun, 3D Home, Yunxi, Shangchuan and other design software
The product also supports Microsoft Excel handmade material lists, has powerful optimization layout programming functions, and can construct simulated products
The substitution operation of actual problems. When workers operate the equipment, they only need to place the workpiece according to the prompts on the computer interface, and the cutting size data is provided by the computer
Intelligent (scan code) refresh, achieving one click operation, usually only requires 2 hours of training to start working.
