Main saw power: 16.5kw
Auxiliary saw motor power: 2.2kw
Maximum sawing length: 2800mm
Maximum sawing thickness: 100mm
Maximum sawing width: 2800mm
Minimum board size for horizontal cutting: 5mm
Minimum vertical cutting board size: 40mm
Positioning method: automatic
Servo positioning accuracy: 0.02mm
Sawing accuracy: ± 0.1mm
Main saw blade outer diameter: 360mm-400mm
Main saw blade inner diameter: 75mm
Main saw speed/frequency converter speed regulation: 4800r/min
Traction motor power (rack drive): 2.0KW
Mechanical arm servo motor: 2.0kw
Side mounted motor: 0.55kw
Sawing speed: 0-100 meters per minute
Return speed: 120 meters per minute
High pressure fan: 4KW
Air pressure: 0.6-0.8MPA
Specification of air flotation table: 1750 * 540mm
Machine tool dimensions: 5180x5950x1900mm
Total power: 27KW
Display screen: 19 inches
