Sawing length: 4300mm
Sawing thickness: 85mm
Main saw blade diameter: Ø 360mm
Main saw shaft diameter: Ø 30mm
Main saw shaft speed/frequency converter speed regulation: 4800rpm
Groove saw blade diameter: Ø 180mm
Groove saw shaft diameter: Ø 25.4mm
Sawing shaft speed/frequency converter speed regulation: 6900rpm
Saw seat forward speed: 100m/min
Saw seat retreat speed: 150m/min
Main saw motor: 16.5kw
Saw seat drive motor: 1.5kw
High voltage blower motor: 4kw 4kw (two)
Total power: 26kw
Automatic feeding speed: 100m/min
Using air pressure: 5-7kg/cm ²
Workbench height above ground: 950mm
Machine dimensions (length * width * height): 6600 * 4500 * 1800mm
The characteristics of reciprocating saws are mainly reflected in cutting efficiency, ease of operation, and multifunctionality:
The reciprocating saw adopts a high-speed motor and short saw blade design, which can quickly cut into materials and complete cutting, especially suitable for handling narrow spaces or fine operations. For example, its maximum stroke can reach 25mm, and with high speed (such as 3000spm), it can greatly improve cutting efficiency.
The body adopts ergonomic design, and the grip part is non slip and lightweight (such as 3.2kg), making it less prone to fatigue after long-term use. Some models support multi speed regulation and one key locking function, which can adapt to the cutting needs of different materials (wood, metal, tiles, etc.).
The reciprocating saw is suitable for cutting various materials, equipped with self-locking clamps and alloy saw blades, with strong stability and durability. For example, the Stanley model can adjust the swing amplitude to adapt to different cutting scenarios, while the Dongcheng model supports infinite speed regulation and is equipped with three spare saw blades.
Some models are equipped with safety lock buttons and battery level display functions to avoid accidental startup and monitor battery status in real time. The soft rubber handle and D-shaped grip design further reduce operational risks.
